HALO Polar – AC3000 Tri-band Whole Home Mesh WiFi System with Touchlink

HALO Polar – AC3000 Tri-band Whole Home Mesh WiFi System with Touchlink

Model: WL-WN551K3

  • Compliant with IEEE 802.11ac/a/n/g/b standards.
  • Extends to maximum 10 other mesh devices of the same series.
  • 3 x 10/100/1000Mbps auto-negotiation Gigabit Ethernet ports.
  • The tri-band technology sorts your devices automatically depending on your device performance, which solves the trouble manually switching to different bands.
  • Simultaneous 5GHz 867Mbps + 1733Mbps and 2.4GHz 400Mbps connection with a total bandwidth of 3000Mbps.
  • Built-in high-power amplifiers provide extensive Wi-Fi coverage and penetration.
  • Patented omni-directional antennas: 4 x 7dBi 5G antennas + 2 x 5dBi 5G antennas + 2 x 5dBi 2.4G antennas, strengthening the WiFi coverage.
  • MU-MIMO technology communicates with several devices at the same time to speed up connection and reduce waiting time.
  • TouchLink function can easily set up a separate and secure WiFi network for visitors and guests to use.
  • USB 2.0 Port - share files & media with networked devices.
Revolutionary Wi-Fi System

Unlike traditional WiFi system, a mesh WiFi system consists of a main device and a few other satellite nodes. They form a single wireless network and share the same SSID and password. With patented Touchlink technology, the WiFi password will never be a headache.

Wide range of coverage

AC3000 mesh system is suitable for various household types, including big apartments or multi-floor houses; whichever set you select, the whole home Wi-Fi system will keep your house covered with wireless signal.

Insanely Fast

Built-in 802.11ac Wi-Fi standard with MIMO technology, each Wi-Fi point delivers data speeds of up to 1200Mbps. Best of all, your whole family will be streaming, gaming and surfing simultaneously without any buffering or lag.

No more dead spots

With various WiFi technologies combined in one system, AC3000 whole home mesh expands the signal coverage more extensively ensuring that no more dead zones will be found again.

Industry-leading hardware security.
Network Optimization Tech. And assign you to the fastest band smartly.
Simple setup and control.
WAVLINK Mesh Wi-Fi System

WAVLINK Wi-Fi nodes work together to create one reliably strong and fast Wi-Fi system. Because mesh system only has one network name and password, you can roam freely without having to switch your devices between networks.

Smart APP

On WAVLINK APP, you can easily manage your network from any Android or iOS device.

Displays every connected device and how much bandwidth they use.
Pause a while for some family time or give your kids a break.
Prioritizes a device to get fastest speed when it matters most.
Signal strength control for stronger penetration through walls and obstacles.
And more…
Patented Touchlink Technology

Tired of sharing the Wi-Fi password constantly when you have a party over or a conference? WAVLINK patented Touchlink will solve your headache, all you need to do is to touch the sensing pad then connect your phone without any password.

Touch and connect.
Easy to share WiFi with your friends.
Saves time in memorizing a complex password.
Beamforming Technology

Beamforming technology is a radio wave tech that’s written into the next generation 802.11ac standard. It searches the position of your devices (such as smart phones, iPad, PC etc) automatically then sends WiFi signal to the specified device directly.

Eight High-performance Antennas

Eight internal antennas increase the reception and sensitivity of every Wi-Fi point to extend over a great coverage.

Blazing-fast Wired Performance

The Gigabit Ethernet runs 10x faster than regular Ethernet connection, which helps your wired devices achieve peak performance for smooth gaming and streaming.

All Ethernet ports of each Wi-Fi point are Gigabit Ethernet ports that support 10/100/1000Mbps speeds.

Elegant Design

Cylindrical design saves much space compared to traditional devices, but it still looks awe-inspiring because of elegance and grace with its soft matte texture. Except for its strong performance, It can be a good match for your home ornamentation.

Two pieces/kit

Applying space: around 2,000 sq.ft.

Three pieces/kit

Applying space: around 3,000 sq.ft.

  • TECHNICAL SPECIFICATIONS
  • Model

    WN551k3

  • Ports

    1 x 10/100/1000Mbps WAN

    2 x 10/100/1000Mbps LAN

    1 x USB 2.0

    1 x DC Power Jack Port

  • Buttons

    1 x Reset button

    1 x Pair button

    1 x Power On/Off button

    1 x Touch button for TouchLink

  • LED

    Halo LED light around the cover

  • Flash

    128Mb

  • SDRAM

    1Gb

  • Power Supply

    DC5V / 4A

  • Rated Voltage / Frequency

    input:100-240 VAC. 50/60Hz

  • DIMENSIONS
  • Unit Dimensions

    119mm x 120mm x 197.6mm ( L x W x H )

  • WIRELESS
  • Standard

    IEEE 802.11a/b/g/n/ac

  • Speed

    IEEE 802.11ac: up to 1733Mbps + 867Mbps

    IEEE 802.11n: up to 400Mbps

    IEEE 802.11g: 54Mbps

    IEEE 802.11b: 11Mbps

    IEEE 802.11a: up to 54Mbps

  • Frequency Band

    2.4GHz, 5GHz

  • Wireless Security

    WPA-PSK/ WPA2-PSK encryption

  • Antennas

    2 x 5dBi 2.4G Omni Directional Antennas

    4 x 7dBi 5G Omni Directional Antennas

    2 x 5dBi 5G Omni Directional Antennas

  • PACKAGE
  • WN551K3

    1 x Mesh Router

    2 x Mesh Satellites

    3 x Power Adapters

    1 x RJ45 Networking Cable

    1 x Quick Guide

  • WN551K2

    1 x Mesh Router

    1 x Mesh Satellite

    2 x Power Adapters

    1 x RJ45 Networking Cable

    1 x Quick Guide
