WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station
  • WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station 1
  • WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station 2
  • WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station 3
  • WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station 4
  • WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station 5

WL-UG69DK5 USB-C Dual 4K Ultra HD Multiple-Display Universal Docking Station

Model: WL-UG69DK5

  • USB3.1 Gen1 Type-C and Standard-A connectors compatible both Type-C and Type-A Laptop
  • Build in USB 3.0 GPU, Plug and Display Certified by DisplayLink
  • 2 x DisplayPort++ (Dual Mode DisplayPort 1.2) and 2 x HDMI (Version 2.0) support resolution up to dual (4K)4096 x 2160@60Hz/(5k)5120x1440@60hz
  • Support resolution (5K)5120 x 2880p60 when dual dp ports are connected to the 5k monitor
  • Support Extend and Mirror Video Mode. 5.1 Channel surround-sound through Display Port interface
  • Gigabit Ethernet network RJ-45 backward 10/100 Ethernet
  • Audio Line-out for Earphone and Line-In Microphone Audio Jack (TRRS)
  • 3 x Type-A + 2 x Type-C ports compatible all USB 3.0 and USB 2.0 devices
USB 3.0 Universal Docking Station

One Dock, for Every Need

Customized for You

13 ports of the most essential connectivity give you all you need in this vertical positioning designed dock.

Multi-function Interface

Better connection for better performance, It’s perfect for anyone who wants to expand their connectivity in virtually any environment or application.

Multitask with Dual 4K Display

Connect your HD monitors to DisplayPort or HDMI ports, then it’ll support dual 4K screens and ultra 5K screens display so that you can play video games, watch clips or work on important projects (such as architecture drawings, medical images and so on) effectively and efficiently.

Three USB3.0 Ports, Two USB-C Ports

In contrast with traditional USB standards, USB3.0 and USB-C both transfer data at 5Gbps, which is blazing-faster than USB2.0, thus, you can transfer files, share images or employ any other relevant process fast as lightning.

Blazing-fast Gigabit Ethernet

Connect your laptop, PC and game consoles to RJ45 Gigabit Ethernet, your multitasking online will be amazingly sped up compared to regular Ethernet port. Theoretically speaking, it supports up to 1 gigabit/second (1000Mbps), thus bandwidth capacity would be largely enhanced.

Two-in-one Audio out & Mic in port

For anyone who wants to access audio files, one can connect microphones, headphones or mini stereos to this “two in one” audio/mic port. Three different devices can be connected to this one port, improving the access experience qualitatively and efficiently.

  • TECHNICAL SPECIFICATIONS
  • Model

    UG69DK5

  • Ports

    1 x Type-C ( Connect to laptop )

    2 x HDMI

    2 x USB-C

    2 x DisplayPort

    3 x USB-A 3.0

    1 x 4-Pole Phone Jack

    1 x RJ45 Gigabit Ethernet

    1 x DC Power Jack Port

  • LED

    Blue

  • Power Supply

    DC20V / 2A

  • DIMENSIONS
  • Unit Dimensions

    192mm x 148mm x 26.20mm ( L x W x H )

  • Housing Material

    ABS

  • Shell Color

    Black

  • FUNCTIONS
  • Working Standards

    Hub running at USB 3.0 speed

    Either DisplayPort or HDMI provided 2 video Output

    Ethernet running at Gigabit

    2.0 Channel Audio

  • Operating System Support

    Windows

    Mac OS X

  • PACKAGE
  • In The Box

    1 x USB-C Universal Docking Station

    1 x USB 3.0 C to C Cable

    1 x USB 3.0 A to C Cable

    1 x DC20V Certified Power Adapter

    1 x User Manual
